Structural

• Hull, solid GRP bottom, Topsides and Structural bulkheads GRP/Navicel PVC foam core

  Quantitities : 80 – 100kgms/m2.
• Vinylester resin to outer layers, isopthalic resin inner.
• Cabin GRP/Navicel PVC foam core

  Quantitities : 80 – 100kgms/m2.
• Internal and non-structural construction in GRP/PPC honeycomb Watertight compartments

  Quantitities : 4
• Foam filled watertight crash area in forepeak

  Quantitities : 2
• Propeller Shaft Stern Tube

  Quantitities : 2
• Rudder Shaft Tube

  Quantitities : 2
• Thru hulls for S/W cooling and ancillary services

  Quantitities : 6
• Overboard discharges

  Quantitities : 6

Hull Finishing

• Primer- epoxy high build surfacing primer, 2 coats

  Quantitities : 2
• Fairing Compound

  Quantitities : 1
• Paint- 2 part polyurethane, Chugoku, 2 coats

  Quantitities : 3
• Antifouling paint 2 coats

  Quantitities : 2
• Non-skid Deck

  Quantitities : 3

Tanks, Piping & Pumps

• Fresh Water Tanks - Fiberglass 200 Liters port side

  Quantitities : 1
• Diesel Fuel Tanks – 700 Litres each – GRP, vinyl ester

  Quantitities : 2
• Senders on Fuel Tanks

  Quantitities : 2
• Diesel Fuel Header Manifold

  Quantitities : 2
• Diesel Fuel Piping Fresh water piping and fittings- HEP2O or Speedfit Shore Water Supply Fitting

  Quantitities : 1
• Salt Water piping Through hull fittings - Bronze

  Quantitities : 6
• Seacock Valves - Bronze

  Quantitities : 6
• Sea Strainers

  Quantitities : 1
• Check Valves

  Quantitities : 3
• Tank Vents

  Quantitities : 6
• Hydraulic Steering Lines/helm pump SeaFirst H/D

  Quantitities : 3
• Bilge Pumping- Manual Amazon

  Quantitities : 1
• Bilge pumps – automatic, Jabsco 3000 GPH

  Quantitities : 2
• Fresh water Pressure Pump, Aquafax 38LPM or similar

  Quantitities : 4
• Waste Piping, low odor Manual pump for waste pumpout w/3 way valve for o/board discharge

  Quantitities : 1
• Black water tank, H/D plastic 120L

  Quantitities : 1

Mechanical

• 140 amp alternator supplied with engine

  Quantitities : 2
• Service batteries, 8D

  Quantitities : 3
• Engine start battery, 120 ampere hour

  Quantitities : 2
• Battery Boxes with Covers for all battery sets

  Quantitities : 3
• Battery isolator/VSR

  Quantitities : 1
• Battery Switches

  Quantitities : 2
• Electrical Wiring – Marine Grade- color coded per USCG Electrical Panel 12VDC

  Quantitities : 1
• Battery monitoring panel

  Quantitities : 1
• Bilge pump control panel

  Quantitities : 1
• Lighting System Wiring 12 VDC

  Quantitities : 1
• Nav lights LED, Hella

  Quantitities : 4
• Anchor Light LED

  Quantitities : 1
• Instrumentation lighting LED

  Quantitities : 2
• Engine Room Lighting flourescent

  Quantitities :2
• Interior lighting LED warm white

  Quantitities :10
• Cockpit lighting LED w/proof

  Quantitities : 2
• Courtesy/ Walkway lighting lights LED, blue

  Quantitities : 10
• Manually controlled halogen search lights

  Quantitities : 2
• Sockets 12 VDC- Helm station and cockpit

  Quantitities : 2
• PVC Conduit for all power wiring

  Quantitities :1

Main Deck Equipment

• Forward facing seating for 70pax Electric Windlass/Capstan, Lewmar V3 with foot switches

  Quantitities : 1
• Front windows – marine grade, clear toughened glass.

  Quantitities : 10mm
• Side window, tinted toughened glass.

  Quantitities : 6mm
• Rear window, tinted toughened glass

  Quantitities : 6mm
• Windscreen wipers/washers, H/D

  Quantitities : 2
• SS guardrails per design Waterproof hatch for Chain Locker

  Quantitities : 1
• Bow Roller, Anchor 16 kg Delta, chain 3/8” High Test, rope ¾”

  Quantitities : 1
• Stern lockers

  Quantitities : 2
• Stowage hatch forward for fenders and mooring lines.

  Quantitities : 1
• Overhead or under seat stowage for life jackets. Cleats, SS - 2 x foredeck 10”, 6 x side 10”

  Quantitities : 8
• Deck Filler Fresh Water- Port & Starboard

  Quantitities : 2
• Deck Filler Diesel Fuel- Port & Starboard

  Quantitities : 2
• Port and starboard boarding points with SS guard rails

Helm Station/Bridge Equipment

• Engine instrument panels

  Quantitities : 1
• SS destroyer type steering wheel Magnetic compass

  Quantitities : 1
• Diesel tank Gauges

  Quantitities : 2
• Fresh Water tank gauges

  Quantitities : 1
• Pilot’s Seat

  Quantitities : 1
• Crew Seat

  Quantitities : 1
• Gear Lockers

  Quantitities : 1
• 12 Volt Horn

  Quantitities : 1

Interior Finish

• Nidacore PVC honeycomb subfloors
• Paint finish for Walls
• Cork or vinyl Flooring
• Ceiling Material- GRP finish panels

Structural

• Compartment equipped with an electric flush toilet and wash basin one each side situated aft

  Quantitities : 2

Safety Equipment

• Lifebuoys, SOLAS

  Quantitities : 6
• First aid kit

  Quantitities : 1
• SOLAS approved life jacket

  Quantitities : 63
• Fire extinguishers 4ltr foam

  Quantitities : 3
• 2.5 kg CO2

  Quantitities : 2
• FireBoy automatic smothering cylinder in engine room

  Quantitities : 2
